前情回顾

部署K8s多节点,首先得署单节master的k8s群集详情参考:

blog.csdn.net/caozhengtao1213/article/details/103987039

本篇内容

1.部署Master2
2.Nginx负载均衡部署-keeplived服务
3.node节点修改配置文件统一VIP
4.创建Pod
5.创建UI显示界面

环境准备

一、部署Master2

1.远程复制master的相关目录

• 关闭防火墙及安全功能

systemctl stop firewalld.servicesetenforce 0

• 复制kubernetes目录到master2

scp -r /opt/kubernetes/ root@192.168.142.120:/opt

• 复制etcd目录到master2(内含证书)

scp -r /opt/etcd/ root@192.168.142.120:/opt

• 复制服务启动脚本到master2

scp /usr/lib/systemd/system/{kube-apiserver,kube-controller-manager,kube-scheduler}.service root@192.168.142.120:/usr/lib/systemd/system/

2.修改kube-apiserver配置文件

vim /opt/kubernetes/cfg/kube-apiserver#将第5和7行IP地址改为master2主机的地址--bind-address=192.168.142.120 --advertise-address=192.168.142.120 \

3.启动服务并设定开机自启

systemctl start kube-apiserver.service systemctl enable kube-apiserver.servicesystemctl start kube-controller-manager.service systemctl enable kube-controller-manager.servicesystemctl start kube-scheduler.servicesystemctl enable kube-scheduler.service

4.追加环境变量并生效

vim /etc/profile#末尾追加export PATH=$PATH:/opt/kubernetes/bin/source /etc/profile

5.查看node节点

kubectl get node

NAME STATUS ROLES AGE VERSION192.168.142.130 Ready <none> 10d12h v1.12.3192.168.142.131 Ready <none> 10d11h v1.12.3

二、Nginx负载均衡部署-keeplived服务

1.在lbm&lbb端的操作,安装nginx服务

• 把nginx.sh和keepalived.conf脚本拷贝到家目录(后面会用到)

#nginx.shcat > /etc/yum.repos.d/nginx.repo << EOF[nginx]name=nginx repobaseurl=http://nginx.org/packages/centos/7/$basearch/gpgcheck=0EOFstream { log_format main ‘$remote_addr $upstream_addr - [$time_local] $status $upstream_bytes_sent‘; access_log /var/log/nginx/k8s-access.log main; upstream k8s-apiserver { server 10.0.0.3:6443; server 10.0.0.8:6443; } server { listen 6443; proxy_pass k8s-apiserver; } }

#keepalived.conf! Configuration File for keepalived global_defs { # 接收邮件地址 notification_email { acassen@firewall.loc failover@firewall.loc sysadmin@firewall.loc } # 邮件发送地址 notification_email_from Alexandre.Cassen@firewall.loc smtp_server 127.0.0.1 smtp_connect_timeout 30 router_id NGINX_MASTER } vrrp_script check_nginx { script "/usr/local/nginx/sbin/check_nginx.sh"}vrrp_instance VI_1 { state MASTER interface eth0 virtual_router_id 51 # VRRP 路由 ID实例，每个实例是唯一的 priority 100 # 优先级，备服务器设置 90 advert_int 1 # 指定VRRP 心跳包通告间隔时间，默认1秒 authentication { auth_type PASS auth_pass 1111 } virtual_ipaddress { 10.0.0.188/24 } track_script { check_nginx } }mkdir /usr/local/nginx/sbin/ -pvim /usr/local/nginx/sbin/check_nginx.shcount=$(ps -ef |grep nginx |egrep -cv "grep|$$")if [ "$count" -eq 0 ];then /etc/init.d/keepalived stopfichmod +x /usr/local/nginx/sbin/check_nginx.sh

• 编辑nginx.repo文件

vim /etc/yum.repos.d/nginx.repo[nginx]name=nginx repobaseurl=http://nginx.org/packages/centos/7/$basearch/gpgcheck=0

• 安装nginx服务

yum install nginx -y

• 添加四层转发

vim /etc/nginx/nginx.conf#在第12行下追加以下内容stream { log_format main ‘$remote_addr $upstream_addr - [$time_local] $status $upstream_bytes_sent‘; access_log /var/log/nginx/k8s-access.log main; upstream k8s-apiserver { server 192.168.142.129:6443; #此处为master的ip地址 server 192.168.142.120:6443; #此处为master2的ip地址 } server { listen 6443; proxy_pass k8s-apiserver; } }

2.部署keeplived服务

#安装keepalivedyum install keepalived -y复制前面的keepalived.conf配置文件，覆盖安装后原有的配置文件cp keepalived.conf /etc/keepalived/keepalived.confvim /etc/keepalived/keepalived.confscript "/etc/nginx/check_nginx.sh" #18行,目录改为/etc/nginx/，脚本后写interface ens33 #23行,eth0改为ens33，此处的网卡名称可以使用ifconfig命令查询virtual_router_id 51 #24行,vrrp路由ID实例，每个实例是唯一的priority 100 #25行,优先级，备服务器设置90virtual_ipaddress { #31行,192.168.142.20/24 #32行,vip地址改为之前设定好的192.168.142.20#38行以下全部删除vim /etc/nginx/check_nginx.sh#统计数量 count=$(ps -ef |grep nginx |egrep -cv "grep|$$") #统计数量#匹配为0，关闭keepalived服务if [ "$count" -eq 0 ];then systemctl stop keepalivedfichmod +x /etc/nginx/check_nginx.sh#启动服务systemctl start keepalived

• 查看地址信息

ip a

# lbm地址信息2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000 link/ether 00:0c:29:eb:11:2a brd ff:ff:ff:ff:ff:ff inet 192.168.142.140/24 brd 192.168.142.255 scope global ens33 valid_lft forever preferred_lft forever inet 192.168.142.20/24 scope global secondary ens33 //漂移地址在lb01中 valid_lft forever preferred_lft forever inet6 fe80::53ba:daab:3e22:e711/64 scope link valid_lft forever preferred_lft forever#lbb地址信息2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000 link/ether 00:0c:29:c9:9d:88 brd ff:ff:ff:ff:ff:ff inet 192.168.142.150/24 brd 192.168.142.255 scope global ens33 valid_lft forever preferred_lft forever inet6 fe80::55c0:6788:9feb:550d/64 scope link valid_lft forever preferred_lft forever

• 验证地址漂移

#停止lbm端的nginx服务pkill nginx#查看服务状态systemctl status nginxsystemctl status keepalived.service#此时判断条件若为0，keepalived服务则是停止的ps -ef |grep nginx |egrep -cv "grep|$$"

• 查看地址信息

ip a

# lbm地址信息2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000 link/ether 00:0c:29:eb:11:2a brd ff:ff:ff:ff:ff:ff inet 192.168.142.140/24 brd 192.168.142.255 scope global ens33 valid_lft forever preferred_lft forever inet6 fe80::53ba:daab:3e22:e711/64 scope link valid_lft forever preferred_lft forever#lbb地址信息2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000 link/ether 00:0c:29:c9:9d:88 brd ff:ff:ff:ff:ff:ff inet 192.168.142.150/24 brd 192.168.142.255 scope global ens33 valid_lft forever preferred_lft forever inet 192.168.142.20/24 scope global secondary ens33 //漂移地址在lb01中 valid_lft forever preferred_lft forever inet6 fe80::55c0:6788:9feb:550d/64 scope link valid_lft forever preferred_lft forever

• 恢复操作

#在lbm端启动nginx和keepalived服务systemctl start nginxsystemctl start keepalived

• 漂移地址回归lbm端

ip a

# lbm地址信息2: ens33: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP qlen 1000 link/ether 00:0c:29:eb:11:2a brd ff:ff:ff:ff:ff:ff inet 192.168.142.140/24 brd 192.168.142.255 scope global ens33 valid_lft forever preferred_lft forever inet 192.168.142.20/24 scope global secondary ens33 //漂移地址在lb01中 valid_lft forever preferred_lft forever inet6 fe80::53ba:daab:3e22:e711/64 scope link valid_lft forever preferred_lft forever

三、node节点修改配置文件统一VIP（bootstrap.kubeconfig,kubelet.kubeconfig）

cd /opt/kubernetes/cfg/#配置文件统一修改为VIPvim /opt/kubernetes/cfg/bootstrap.kubeconfigserver: https://192.168.142.20:6443 #第5行改为Vip的地址vim /opt/kubernetes/cfg/kubelet.kubeconfigserver: https://192.168.142.20:6443 #第5行改为Vip的地址vim /opt/kubernetes/cfg/kube-proxy.kubeconfigserver: https://192.168.142.20:6443 #第5行改为Vip的地址

• 替换完成后自检

grep 20 *

bootstrap.kubeconfig: server: https://192.168.142.20:6443kubelet.kubeconfig: server: https://192.168.142.20:6443kube-proxy.kubeconfig: server: https://192.168.142.20:6443

• 在lb01上查看nginx的k8s日志

tail /var/log/nginx/k8s-access.log

192.168.142.140 192.168.142.129:6443 - [08/Feb/2020:19:20:40 +0800] 200 1119192.168.142.140 192.168.142.120:6443 - [08/Feb/2020:19:20:40 +0800] 200 1119192.168.142.150 192.168.142.129:6443 - [08/Feb/2020:19:20:44 +0800] 200 1120192.168.142.150 192.168.142.120:6443 - [08/Feb/2020:19:20:44 +0800] 200 1120

四、创建Pod

• 测试创建Pod

kubectl run nginx --image=nginx

• 查看状态

kubectl get pods

• 绑定群集中的匿名用户赋予管理员权限(解决日志不可看问题)

kubectl create clusterrolebinding cluster-system-anonymous --clusterrole=cluster-admin --user=system:anonymous

• 查看Pod网络

kubectl get pods -o wid

五、创建UI显示界面

• 在master1上创建dashborad工作目录

mkdir /k8s/dashboardcd /k8s/dashboard#上传官方的文件到该目录中

• 创建页面，注意顺序

#授权访问apikubectl create -f dashboard-rbac.yaml#进行加密kubectl create -f dashboard-secret.yaml#配置应用kubectl create -f dashboard-configmap.yaml#控制器kubectl create -f dashboard-controller.yaml#发布出去进行访问kubectl create -f dashboard-service.yaml

• 完成后查看创建在指定的kube-system命名空间下

kubectl get pods -n kube-system

• 查看如何访问

kubectl get pods,svc -n kube-system

• 在浏览器中输入nodeIP地址就可以访问(谷歌浏览器无法访问题解决方法)

1.在master端操作,编写进行证书自签

vim dashboard-cert.shcat > dashboard-csr.json <<EOF{ "CN": "Dashboard", "hosts": [], "key": { "algo": "rsa", "size": 2048 }, "names": [ { "C": "CN", "L": "NanJing", "ST": "NanJing" } ]}EOFK8S_CA=$1cfssl gencert -ca=$K8S_CA/ca.pem -ca-key=$K8S_CA/ca-key.pem -config=$K8S_CA/ca-config.json -profile=kubernetes dashboard-csr.json | cfssljson -bare dashboardkubectl delete secret kubernetes-dashboard-certs -n kube-systemkubectl create secret generic kubernetes-dashboard-certs --from-file=./ -n kube-system

2.重新应用新的自签证书

bash dashboard-cert.sh /root/k8s/apiserver/

3.修改yaml文件

vim dashboard-controller.yaml#在47行下追加以下内容 - --tls-key-file=dashboard-key.pem - --tls-cert-file=dashboard.pem

4.重新进行部署

kubectl apply -f dashboard-controller.yaml

5.生成登录令牌

• 生成令牌

kubectl create -f k8s-admin.yaml

• 将令牌保存

kubectl get secret -n kube-system

NAME TYPE DATA AGEdashboard-admin-token-drs7c kubernetes.io/service-account-token 3 60sdefault-token-mmvcg kubernetes.io/service-account-token 3 55mkubernetes-dashboard-certs Opaque 10 10mkubernetes-dashboard-key-holder Opaque 2 23mkubernetes-dashboard-token-crqvs kubernetes.io/service-account-token 3 23m

• 查看令牌

kubectl describe secret dashboard-admin-token-drs7c -n kube-system

6.复制粘贴令牌后,登录到UI界面

谢谢阅读!
