从一次生产消费者的bug看看线程池如何增加线程

0 背景

某个闲来无事的下午,看到旧有的项目中,有个任务调度的地方都是同步的操作,就是流程A的完成依赖流程B,流程B的完成依赖流程C,按此类推。

作为一名垃圾代码生产者,QA的噩梦、故障报告枪手的我来说,发掘可以“优化”的空间,是我的分内之事。

因为是在一个工程内,并且本身工程组件没有使用到任何消息队列的软件(例如kafka、rocketMQ),如果只是要因为这个功能而贸然引用,对其进行维护的成本就比较高,我的技术组长大人是万万不会同意的。没办法,自己来吧。很快的,我完成了下面几个类的编写

整体的设计很简单,就是传统的生产消费者,只是利用了阻塞队列,作为缓冲。

  • 在生产者内部有个定时执行的线程,将队列中的消息转发给消费者。生产者会单独占用一个线程
  • 每个消费者自己也有一个阻塞队列,用来接收生产者产生的消息,消费者们因为可能不是所有的topic每时每刻都会有消息的产生,因此利用线程池即可。

1 代码实现


public interface IEvent {

    String getTopic();

}

// 消息实体
public class Event<T> implements IEvent{

    /**
     * 产生的时间戳
     */
    private long ts = System.currentTimeMillis();

    /**
     * 携带的实体数据
     */
    private T entity;


    /**
     * topic
     */
    private String topic;


    // setter getter 省略
}

// 如何处理消息
public interface ConfigListener {

    String ALL = "all";

    /**
     * 提供给监听器处理
     *
     * @param event
     */
    void handler(IEvent event);


    /**
     * 优先级顺序 值越大优先级越高
     * @return
     */
    int getOrder();

    /**
     *
     * @return
     */
    String getTopic();

}

// 创建4个消息处理的类,这里省略了,只展示一个
public class RandomSleepConfigListener implements ConfigListener {

    @Override
    public void handler(IEvent event) {
        logger.info("execute " + this.getClass().getSimpleName());
        // 20ms - 50ms
        long t = (long) (Math.random() * 5) + 5L;
        try {
            TimeUnit.MILLISECONDS.sleep(t);
        } catch (InterruptedException e) {
            e.printStackTrace();
        }
    }

    @Override
    public int getOrder() {
        return 0;
    }

    @Override
    public String getTopic() {
        return "random1";
    }
}




// 线程池类
public class ScheduleThreadPool {

    private static final AtomicInteger atomic = new AtomicInteger();

    // 被生产者单独使用的线程
    public static final ExecutorService EVENT_POOL = Executors.newFixedThreadPool(1, r -> new Thread(r, "EVENT-PRODUCER-" + atomic.incrementAndGet()));

    /**
     * 常驻线程2个,最大8个,最多接受任务128个,超过则由提交线程来处理
     */
    public static final ExecutorService EVENT_CONSUMER_POOL =
            new ThreadPoolExecutor(2, 8, 50L,
                    TimeUnit.MILLISECONDS,
                    new ArrayBlockingQueue<>(128),
                    r -> new Thread(r, "EVENT-CONSUMER-" + atomic.incrementAndGet()),
                    new ThreadPoolExecutor.CallerRunsPolicy());
}



// ############################### 以上的准备工作完成,下面就是编写生产者和消费者     ###########################################


public class Producer {

    private static final Logger logger = LoggerFactory.getLogger(MethodHandles.lookup().lookupClass());

    /**
     * 外部提交的消息体会被送入到这个队列当中
     */
    private static final ArrayBlockingQueue<IEvent> blockingQueue = new ArrayBlockingQueue<>(128);

    /**
     *  topic, consumer
     */
    private static Map<String, Consumer> topic2ConsumerMap = Maps.newHashMap();



    // 一些初始化的工作
    static {
        logger.info("Producer init start...");
        // SPI方式插件式加载,这里可以改为你熟悉的加载类的方式
        Iterator<ConfigListener> configListenerIterator = ServiceBootstrap.loadAll(ConfigListener.class);

        // 整体遍历一遍,不同的listener分散到不同的地方去
        while (configListenerIterator.hasNext()) {
            ConfigListener configListener = configListenerIterator.next();
            String topic = configListener.getTopic();
            // 没有明确topic的,我们不进行处理
            if (null == topic) {
                continue;
            }

            logger.info("we init {} topic", topic);

            if (topic2ConsumerMap.containsKey(topic)) {
                topic2ConsumerMap.get(topic).addListener(configListener);
            } else {
                topic2ConsumerMap.put(topic, new Consumer(topic).addListener(configListener));
            }
        }

        // 如果有定义对全部都适用的事件处理,需要加入到每个topic的listener的队列中去
        if (topic2ConsumerMap.containsKey(ConfigListener.ALL)) {
            Consumer consumer = topic2ConsumerMap.get(ConfigListener.ALL);
            topic2ConsumerMap.remove(ConfigListener.ALL);

            for (Map.Entry<String, Consumer> entry : topic2ConsumerMap.entrySet()) {
                entry.getValue().addAllListener(consumer.getPriorityList());
            }
        }

        // 启动监听线程
        ScheduleThreadPool.EVENT_POOL.execute(() -> {
            //noinspection InfiniteLoopStatement
            int i = 0;
            while (true) {
                try {
                    // 从队列获取需要处理的任务,没有会进行阻塞
                    IEvent iEvent = blockingQueue.take();
                    logger.info("from producer queue take a message {} {}", iEvent.getTopic(), (i++));
                    topic2ConsumerMap.get(iEvent.getTopic()).addEvent(iEvent);
                } catch (InterruptedException e) {
                    //
                }
            }
        });

        logger.info("Producer init end...");
    }


    /**
     * 阻塞队列添加要处理的事件
     * @param iEvent
     * @return true 添加成功
     */
    public static void publish(IEvent iEvent) throws InterruptedException {
        logger.info("publish start...");
        // 当队列满时,这个方法会被阻塞
        blockingQueue.put(iEvent);
        logger.info("publish over...");
    }

}



public class Consumer {

    private static final Logger logger = LoggerFactory.getLogger(MethodHandles.lookup().lookupClass());

    /**
     * 排序好的列表
     */
    private List<ConfigListener> priorityList = Lists.newArrayListWithCapacity(16);

    /**
     * 降序排列
     */
    private Comparator<ConfigListener> comparator = (o1, o2) -> o2.getOrder() - o1.getOrder();


    /**
     * 等待被处理的事件
     */
    private LinkedBlockingQueue<IEvent> waitEvent = new LinkedBlockingQueue<>(32);

    /**
     * 统计已经完成的任务数
     */
    private AtomicInteger count = new AtomicInteger();

    /**
     * 处理哪种topic
     */
    private String topic;

//    //CODE-B 这块代码是后来产生问题的代码,也是因为这个代码引起了我对线程池创建过程的好奇
//    {
//        logger.info("non-static invoke--------");
//        // 创建任务提交
//        ScheduleThreadPool.EVENT_CONSUMER_POOL.execute(() -> {
//            // 注意这里有个循环
//            for (;;) {
//                try {
//                    logger.info("take event");
//                    IEvent take = waitEvent.take();
//                    priorityList.forEach(c -> c.handler(take));
//                    int t = count.incrementAndGet();
//                    logger.info("TOPIC[{}] size {}, remainingCapacity {} finish {} ",
//                            topic, waitEvent.size(), waitEvent.remainingCapacity(), t);
//                } catch (InterruptedException e) {
//                    // 记录错误失败
//                }
//            }
//        });
//    }

    public Consumer(String topic) {
        this.topic = topic;
    }


    public List<ConfigListener> getPriorityList() {
        return priorityList;
    }

    public Consumer addListener(ConfigListener listener) {
        priorityList.add(listener);
        priorityList.sort(comparator);
        return this;
    }

    public void addAllListener(Collection<? extends ConfigListener> c) {
        priorityList.addAll(c);
        priorityList.sort(comparator);
    }

    public void addEvent(IEvent iEvent) {
        try {
            logger.info(" topic {} queueSize {} finish {}", this.topic, waitEvent.size(), count.get());
            waitEvent.put(iEvent);
        } catch (InterruptedException e) {
            //
        }


        // CODE-A
        ScheduleThreadPool.EVENT_CONSUMER_POOL.execute(() -> {
            // 注意这里和分发的producer不一样,不使用循环
            try {
                logger.info("take event");
                IEvent take = waitEvent.take();
                priorityList.forEach(c -> c.handler(take));
                int t = count.incrementAndGet();
                logger.info("TOPIC[{}] size {}, remainingCapacity {} finish {} ",
                        topic, waitEvent.size(), waitEvent.remainingCapacity(), t);
            } catch (InterruptedException e) {
                // 记录错误失败
            }
        });

    }

}


// 测试类
public class ProductTest{
    // 这里我自己创建了4个消息处理的类,对应的topic分别如下
    String[] topics = {"random1","random2","random3","random4"};

    @Test(timeout = 30000L)
    public void publish() throws InterruptedException {

        for (int i = 0; i < 720; i++) {
            int j = i & 0x3;
            System.out.println(i);
            Producer.publish(new Event<String>("hello", topics[j]));
        }

        TimeUnit.SECONDS.sleep(60L);
    }

}

2 开搞

代码都准备好了以后,我们就开始了,debug出来的结果和设想的符合预期

4个topic,720个任务,每个处理掉180个

2021-01-17 16:27:56.210 [EVENT-CONSUMER-3] INFO  - TOPIC[random1] size 0, remainingCapacity 32 finish 180
2021-01-17 16:27:56.210 [EVENT-CONSUMER-2] INFO  - TOPIC[random4] size 1, remainingCapacity 31 finish 179
2021-01-17 16:27:56.210 [EVENT-CONSUMER-3] INFO  - take event
2021-01-17 16:27:56.210 [EVENT-CONSUMER-2] INFO  - take event
2021-01-17 16:27:56.210 [EVENT-CONSUMER-3] INFO  - execute RandomSleepConfigListener2
2021-01-17 16:27:56.210 [EVENT-CONSUMER-2] INFO  - execute RandomSleepConfigListener3
2021-01-17 16:27:56.215 [EVENT-CONSUMER-3] INFO  - TOPIC[random2] size 0, remainingCapacity 32 finish 180
2021-01-17 16:27:56.215 [EVENT-CONSUMER-3] INFO  - take event
2021-01-17 16:27:56.215 [EVENT-CONSUMER-3] INFO  - execute RandomSleepConfigListener4
2021-01-17 16:27:56.217 [EVENT-CONSUMER-2] INFO  - TOPIC[random3] size 0, remainingCapacity 32 finish 180
2021-01-17 16:27:56.221 [EVENT-CONSUMER-3] INFO  - TOPIC[random4] size 0, remainingCapacity 32 finish 180

嗯,目前为止觉得很完美,然后看consumer类,觉得每次任务被推入阻塞队列,然后执行线程去从阻塞队列中去拉取消息出来,这不符合我作死的风格,改。
然后就变为了CODE-B的模样,线程池创建出来后,一直循环来拉取即可

    {
        logger.info("non-static invoke--------");
        // 创建任务提交
        ScheduleThreadPool.EVENT_CONSUMER_POOL.execute(() -> {
            // 注意这里有个循环
            for (;;) {
                try {
                    logger.info("take event");
                    IEvent take = waitEvent.take();
                    priorityList.forEach(c -> c.handler(take));
                    int t = count.incrementAndGet();
                    logger.info("TOPIC[{}] size {}, remainingCapacity {} finish {} ",
                            topic, waitEvent.size(), waitEvent.remainingCapacity(), t);
                } catch (InterruptedException e) {
                    // 记录错误失败
                }
            }
        });
    }

然后,将CODE-A的代码注释掉,神奇的事情就发生了,直接一发入魂

2021-01-17 16:32:49.539 [Time-limited test] INFO  - Producer init start...
2021-01-17 16:32:49.562 [Time-limited test] INFO  - we init all topic
2021-01-17 16:32:49.806 [Time-limited test] INFO  - non-static invoke--------   ##########
2021-01-17 16:32:49.819 [Time-limited test] INFO  - we init random1 topic
2021-01-17 16:32:49.819 [Time-limited test] INFO  - non-static invoke--------   ##########
2021-01-17 16:32:49.819 [EVENT-CONSUMER-1] INFO  - take event**                 ##########
2021-01-17 16:32:49.820 [EVENT-CONSUMER-2] INFO  - take event**                 ##########
2021-01-17 16:32:49.821 [Time-limited test] INFO  - we init random2 topic
2021-01-17 16:32:49.821 [Time-limited test] INFO  - non-static invoke--------
2021-01-17 16:32:49.824 [Time-limited test] INFO  - we init random3 topic
2021-01-17 16:32:49.824 [Time-limited test] INFO  - non-static invoke--------
2021-01-17 16:32:49.826 [Time-limited test] INFO  - we init random4 topic
2021-01-17 16:32:49.880 [Time-limited test] INFO  - non-static invoke--------
2021-01-17 16:32:49.884 [Time-limited test] INFO  - Producer init end...
2021-01-17 16:32:49.884 [Time-limited test] INFO  - publish start...
2021-01-17 16:32:49.884 [Time-limited test] INFO  - publish over...



2021-01-17 16:32:49.885 [ **EVENT-PRODUCER-3** ] INFO  -  topic random1 queueSize 0 finish 0     ##########
2021-01-17 16:32:49.885 [Time-limited test] INFO  - publish over...

2021-01-17 16:32:49.886 [EVENT-PRODUCER-3] INFO  - from producer queue take a message random2 1
2021-01-17 16:32:49.886 [Time-limited test] INFO  - publish start...
2021-01-17 16:32:49.886 [ **EVENT-PRODUCER-3** ] INFO  -  topic random2 queueSize 0 finish 0      ##########
2021-01-17 16:32:49.886 [Time-limited test] INFO  - publish over...

2021-01-17 16:32:49.886 [EVENT-PRODUCER-3] INFO  - from producer queue take a message random3 2
2021-01-17 16:32:49.886 [Time-limited test] INFO  - publish start...
2021-01-17 16:32:49.886 [**EVENT-PRODUCER-3**] INFO  -  topic random3 queueSize 0 finish 0        ##########
2021-01-17 16:32:49.886 [Time-limited test] INFO  - publish over...

2021-01-17 16:32:49.886 [EVENT-PRODUCER-3] INFO  - from producer queue take a message random4 3
2021-01-17 16:32:49.886 [**EVENT-PRODUCER-3**] INFO  -  topic random4 queueSize 0 finish 0        ##########

....

2021-01-17 16:32:50.031 [EVENT-PRODUCER-3] INFO  -  topic random1 queueSize 27 finish 5
2021-01-17 16:32:50.031 [EVENT-PRODUCER-3] INFO  - from producer queue take a message random2 129
2021-01-17 16:32:50.031 [EVENT-PRODUCER-3] INFO  -  topic random2 queueSize 32 finish 0
.
.
.

2021-01-17 16:32:50.275 [EVENT-CONSUMER-2] INFO  - execute RandomSleepConfigListener
2021-01-17 16:32:50.283 [EVENT-CONSUMER-2] INFO  - TOPIC[random1] size 4, remainingCapacity 28 finish 29
2021-01-17 16:32:50.283 [EVENT-CONSUMER-2] INFO  - take event
2021-01-17 16:32:50.283 [EVENT-CONSUMER-2] INFO  - execute RandomSleepConfigListener
2021-01-17 16:32:50.289 [EVENT-CONSUMER-2] INFO  - TOPIC[random1] size 3, remainingCapacity 29 finish 30
2021-01-17 16:32:50.290 [EVENT-CONSUMER-2] INFO  - take event
2021-01-17 16:32:50.290 [EVENT-CONSUMER-2] INFO  - execute RandomSleepConfigListener
2021-01-17 16:32:50.299 [EVENT-CONSUMER-2] INFO  - TOPIC[random1] size 2, remainingCapacity 30 finish 31
2021-01-17 16:32:50.299 [EVENT-CONSUMER-2] INFO  - take event
2021-01-17 16:32:50.299 [EVENT-CONSUMER-2] INFO  - execute RandomSleepConfigListener
2021-01-17 16:32:50.305 [EVENT-CONSUMER-2] INFO  - TOPIC[random1] size 1, remainingCapacity 31 finish 32
2021-01-17 16:32:50.305 [EVENT-CONSUMER-2] INFO  - take event
2021-01-17 16:32:50.306 [EVENT-CONSUMER-2] INFO  - execute RandomSleepConfigListener
2021-01-17 16:32:50.315 [EVENT-CONSUMER-2] INFO  - TOPIC[random1] size 0, remainingCapacity 32 finish 33
2021-01-17 16:32:50.316 [EVENT-CONSUMER-2] INFO  - take event

看日志是只有topic1被消费了,其他的topic都没有被消费。

第一段和第二段表明,生产者是如期按照我们设想的,逐个将详细进行分发,我的测试程序是按顺序进行1~4的消息分发的。

EVENT-CONSUMER的线程编号只有到2,3是属于生产者线程的编号。于是我就感觉很奇怪,为什么线程池没有继续创建线程呢?

3 分析原因

我开始去查看了线程池execute()这个方法

public void execute(Runnable command) {
        if (command == null)
            throw new NullPointerException();
        /*
         * Proceed in 3 steps:
         *
         * 1. If fewer than corePoolSize threads are running, try to
         * start a new thread with the given command as its first
         * task.  The call to addWorker atomically checks runState and
         * workerCount, and so prevents false alarms that would add
         * threads when it shouldn't, by returning false.
         *
         * 2. If a task can be successfully queued, then we still need
         * to double-check whether we should have added a thread
         * (because existing ones died since last checking) or that
         * the pool shut down since entry into this method. So we
         * recheck state and if necessary roll back the enqueuing if
         * stopped, or start a new thread if there are none.
         *
         * 3. If we cannot queue task, then we try to add a new
         * thread.  If it fails, we know we are shut down or saturated
         * and so reject the task.
         */
        int c = ctl.get();
        if (workerCountOf(c) < corePoolSize) {
            if (addWorker(command, true))
                return;
            c = ctl.get();
        }
        if (isRunning(c) && workQueue.offer(command)) {
            int recheck = ctl.get();
            if (! isRunning(recheck) && remove(command))
                reject(command);
            else if (workerCountOf(recheck) == 0)    // ------------  debug后发现进入到这里条件无法满足
                addWorker(null, false);
        }
        else if (!addWorker(command, false))
            reject(command);
    }

英文注释解释的很明白,execute在线程创建方面有会进行3种情况考虑

1 本身workthread 小于 coresize 则果断进行创建

2 线程池处于运行状态,将要执行的命令进行入队,这个入队就是我们在创建线程池时使用的队列,我这里用的是128个

3 进入到第三部可能是线程池已经关闭了,或者是队列已经满了,如果是关闭,这一步肯定会失败,如果是队列满了那么也是同样的,之所以要再直接创建工作线程,是因为可能这个瞬间刚好有机会创建,因此不放弃这种可行性。

4 哦豁是这样

随后我就行了debug大法,发现一开始的2个消费者线程都是创建的十分的顺利,但是后面的线程任务就没办法了创建出新的线程了。

仔细观察,发现是if (workerCountOf(recheck) == 0)到这一步判断不满足条件,就不往下进行创建了。

在我的场景下,工作线程数肯定不会为0,所以这个条件一定是无法满足,那么要创建出线程,只能是满足条件3。那似乎只要堆满线程池的阻塞队列就可以了,是吗?

将线程池阻塞队列的大小,修改为16,重新执行,发现整体还是会卡住,并且也没有新的线程被创建。这个时候就很明显了,是有个地方卡住,而无法增加更多的线程池任务。

**至于卡住的原因,使用阻塞队列,一定是某一个阻塞了。从后面观察来看,是生产者的缓冲队列满了。只进行到32的原因,也是因为刚好每个消费者的缓冲队列是32的大小。4个就是一个生产者的队列长度。当第一批128个分发玩了以后,从129开始,给topic1以外(topic2,topic3,topic4因为都没有机会被消费掉)的队列已经满了,put进行的阻塞。于是生产者和消费者处于全员懵逼的状态。于是只有topic1是被消费完整的,处于take()等待的状态 **

最开始没有使用死循环的代码就和一般我们写的多线程代码一样,大家都靠本事去竞争,因此每个consumer都有机会被执行。

那么最后一个问题,要想让线程池创建超过coreSize的线程要怎么做呢?从注释长短你就能看出,哪些条件比较简单,满足条件3只要我们创造多一些任务即可,或者将线程池的工作队列大小调小。(这里我选择调整队列大小,改为16,很快就创建出新的线程了)

5 结论

那么线程池创建的哲学是什么?

首先,按照coreSize,创建出24h不间断休息的好员工
其次,有处理不来的工作先堆放到某个地方,等待处理
最后,核心员工不行,赶紧招募临时工,来一起进行攻坚

希望这篇文章对你理解线程池有所帮助。纰漏之处,欢迎拍砖

发表评论

评论已关闭。

相关文章
