转自：http://www.cuiyongzhi.com/post/34.html
前面一篇有说道如何在MyEclipse中搭建maven项目，这里将继续介绍如何在搭建好的基础maven项目中引入我们常用的javaweb框架——SpringMVC！
①在建立好的maven项目中的pom.xml文件引入依赖，代码如下：
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 | <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd"> <modelVersion>4.0.0</modelVersion> <groupId>wechat.cuiyongzhi.com</groupId> <artifactId>wechat</artifactId> <packaging>war</packaging> <version>0.0.1-SNAPSHOT</version> <name>wechat</name> <url>http://maven.apache.org</url> <dependencies> <!-- spring --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-test</artifactId> <version>3.2.0.RELEASE</version> </dependency> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-webmvc</artifactId> <version>3.2.0.RELEASE</version> </dependency> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-core</artifactId> <version>3.2.0.RELEASE</version> </dependency> <!-- mybatis --> <dependency> <groupId>org.mybatis</groupId> <artifactId>mybatis</artifactId> <version>3.1.1</version> </dependency> <dependency> <groupId>org.mybatis</groupId> <artifactId>mybatis-spring</artifactId> <version>1.1.1</version> </dependency> <!-- mysql --> <dependency> <groupId>mysql</groupId> <artifactId>mysql-connector-java</artifactId> <version>5.1.21</version> </dependency> <!-- junit测试 --> <dependency> <groupId>junit</groupId> <artifactId>junit</artifactId> <version>4.11</version> <scope>test</scope> </dependency> <!-- mysql阿里连接池druid --> <dependency> <groupId>com.alibaba</groupId> <artifactId>druid</artifactId> <version>0.2.9</version> </dependency> <!-- spring aop包 --> <dependency> <groupId>org.aspectj</groupId> <artifactId>aspectjweaver</artifactId> <version>1.7.1</version> </dependency> <!-- json包 --> <dependency> <groupId>com.alibaba</groupId> <artifactId>fastjson</artifactId> <version>1.2.7</version> </dependency> <!-- 文件上传包 --> <dependency> <groupId>commons-fileupload</groupId> <artifactId>commons-fileupload</artifactId> <version>1.2.2</version> </dependency> <!--servlet包 --> <dependency> <groupId>javax.servlet</groupId> <artifactId>servlet-api</artifactId> <version>3.0-alpha-1</version> </dependency> <dependency> <groupId>javax.servlet.jsp</groupId> <artifactId>jsp-api</artifactId> <version>2.1</version> <scope>provided</scope> </dependency> <dependency> <groupId>javax.servlet</groupId> <artifactId>jstl</artifactId> <version>1.2</version> </dependency> <!-- 日志包 --> <dependency> <groupId>log4j</groupId> <artifactId>log4j</artifactId> <version>1.2.17</version> </dependency> </dependencies> <build> <finalName>wechat</finalName> </build> </project> |
②修改项目路径下的web.xml文件如下：
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 | <?xml version="1.0" encoding="UTF-8"?> <web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:web="http://java.sun.com/xml/ns/javaee" xmlns="http://java.sun.com/xml/ns/javaee" xsi:schemaLocation="http://java.sun.com/xml/ns/javaee http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd http://www.springframework.org/schema/websocket http://www.springframework.org/schema/websocket/spring-websocket.xsd" id="WebApp_ID" version="3.0"> <display-name>com.cuiyongzhi.wechat</display-name> <context-param> <param-name>contextConfigLocation</param-name> <param-value>classpath:spring.xml,classpath:spring-mybatis.xml</param-value> <!-- ,classpath:spring-quartz.xml 用于做任务调度 任务定时都可以 --> </context-param> <context-param> <param-name>log4jConfigLocation</param-name> <param-value>classpath:log4j.properties</param-value> </context-param> <listener> <listener-class>org.springframework.web.util.Log4jConfigListener</listener-class> </listener> <context-param> <param-name>spring.profiles.active</param-name> <param-value>dev</param-value> </context-param> <context-param> <param-name>spring.profiles.default</param-name> <param-value>dev</param-value> </context-param> <context-param> <param-name>spring.liveBeansView.mbeanDomain</param-name> <param-value>dev</param-value> </context-param> <filter> <filter-name>encodingFilter</filter-name> <filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class> <init-param> <param-name>encoding</param-name> <param-value>UTF-8</param-value> </init-param> <init-param> <param-name>forceEncoding</param-name> <param-value>true</param-value> </init-param> </filter> <listener> <description>spring监听器</description> <listener-class>org.springframework.web.context.ContextLoaderListener</listener-class> </listener> <!-- 防止内存溢出 --> <listener> <listener-class>org.springframework.web.util.IntrospectorCleanupListener</listener-class> </listener> <servlet> <description>spring mvc servlet</description> <servlet-name>springMvc</servlet-name> <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class> <init-param> <description>spring mvc 配置文件</description> <param-name>contextConfigLocation</param-name> <param-value>classpath:spring-mvc.xml</param-value> </init-param> <load-on-startup>1</load-on-startup> </servlet> <servlet> <servlet-name>interface_url-init_servlet</servlet-name> <servlet-class>com.cuiyongzhi.web.start.InterfaceUrlIntiServlet</servlet-class> <load-on-startup>1</load-on-startup> </servlet> <servlet-mapping> <servlet-name>springMvc</servlet-name> <url-pattern>/</url-pattern> </servlet-mapping> <welcome-file-list> <welcome-file>/index.jsp</welcome-file> </welcome-file-list> <session-config> <session-timeout>300</session-timeout> </session-config> <error-page> <error-code>404</error-code> <location>/WEB-INF/error/error.jsp</location> </error-page> <error-page> <error-code>500</error-code> <location>/WEB-INF/error/error.jsp</location> </error-page> <servlet-mapping> <servlet-name>default</servlet-name> <url-pattern>*.css</url-pattern> </servlet-mapping> <servlet-mapping> <servlet-name>default</servlet-name> <url-pattern>*.gif</url-pattern> </servlet-mapping> <servlet-mapping> <servlet-name>default</servlet-name> <url-pattern>*.jpg</url-pattern> </servlet-mapping> <servlet-mapping> <servlet-name>default</servlet-name> <url-pattern>*.js</url-pattern> </servlet-mapping> <servlet-mapping> <servlet-name>default</servlet-name> <url-pattern>*.xhtml</url-pattern> </servlet-mapping> <servlet-mapping> <servlet-name>default</servlet-name> <url-pattern>*.html</url-pattern> </servlet-mapping> <filter> <filter-name>DruidWebStatFilter</filter-name> <filter-class>com.alibaba.druid.support.http.WebStatFilter</filter-class> <init-param> <param-name>exclusions</param-name> <param-value>*.js,*.gif,*.jpg,*.png,*.css,*.ico,/druid/*</param-value> </init-param> </filter> <filter-mapping> <filter-name>DruidWebStatFilter</filter-name> <url-pattern>/*</url-pattern> </filter-mapping> <servlet> <servlet-name>DruidStatView</servlet-name> <servlet-class>com.alibaba.druid.support.http.StatViewServlet</servlet-class> <init-param> <!-- 允许清空统计数据 --> <param-name>resetEnable</param-name> <param-value>true</param-value> </init-param> <init-param> <!-- 用户名 --> <param-name>loginUsername</param-name> <param-value>cuiyongzhi</param-value> </init-param> <init-param> <!-- 密码 --> <param-name>loginPassword</param-name> <param-value>123456</param-value> </init-param> </servlet> <servlet-mapping> <servlet-name>DruidStatView</servlet-name> <url-pattern>/druid/*</url-pattern> </servlet-mapping> <!-- 访问监控页面：http://ip：port/projectName/druid/index.html --> <jsp-config> <jsp-property-group> <display-name>jspConfiguration</display-name> <url-pattern>*.jsp</url-pattern> <el-ignored>false</el-ignored> <scripting-invalid>false</scripting-invalid> <include-prelude>/WEB-INF/common/head.jsp</include-prelude> </jsp-property-group> </jsp-config> </web-app> |
③添加数据库配置信息，这里项目配置的数据库为mysql，在 resources下新建config.properties配置文件，设置如下：
1 2 3 4 | validationQuery=SELECT 1 jdbc_url=jdbc:mysql://127.0.0.1:3306/wechat?useUnicode=true&characterEncoding=UTF-8&zeroDateTimeBehavior=convertToNull jdbc_username=root jdbc_password=123456789 |
④在 resources下新建spring.xml配置文件，设置如下：
1 2 3 4 5 6 7 8 9 10 11 12 13 | <?xml version="1.0" encoding="UTF-8"?> <beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:context="http://www.springframework.org/schema/context" xsi:schemaLocation=" http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-3.0.xsd http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context-3.0.xsd"> <!-- 引入属性文件 --> <context:property-placeholder location="classpath:config.properties" /> <!-- 自动扫描(自动注入) --> <context:component-scan base-package="com.cuiyongzhi.web.service" /> <context:component-scan base-package="com.cuiyongzhi.wechat.*" /> </beans> |
⑤在 resources下新建spring-mvc.xml配置文件，设置如下：
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 | <?xml version="1.0" encoding="UTF-8"?> <beans xmlns="http://www.springframework.org/schema/beans" xmlns:mvc="http://www.springframework.org/schema/mvc" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:p="http://www.springframework.org/schema/p" xmlns:context="http://www.springframework.org/schema/context" xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-4.0.xsd http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context-4.0.xsd http://www.springframework.org/schema/mvc http://www.springframework.org/schema/mvc/spring-mvc-4.0.xsd"> <!-- 自动扫描controller包下的所有类，使其认为spring mvc的控制器 --> <context:component-scan base-package="com.cuiyongzhi.web.controller" /> <!-- 避免IE执行AJAX时,返回JSON出现下载文件 --> <bean id="mappingJacksonHttpMessageConverter" class="org.springframework.http.converter.json.MappingJacksonHttpMessageConverter"> <property name="supportedMediaTypes"> <list> <value>text/html;charset=UTF-8</value> </list> </property> </bean> <!-- 启动Spring MVC的注解功能，完成请求和注解POJO的映射 --> <bean class="org.springframework.web.servlet.mvc.annotation.AnnotationMethodHandlerAdapter"> <property name="messageConverters"> <list> <ref bean="mappingJacksonHttpMessageConverter" /><!-- json转换器 --> </list> </property> </bean> <!-- 对模型视图名称的解析，即在模型视图名称添加前后缀 --> <bean class="org.springframework.web.servlet.view.InternalResourceViewResolver" p:prefix="/WEB-INF/views/" p:suffix=".jsp" /> <bean id="multipartResolver" class="org.springframework.web.multipart.commons.CommonsMultipartResolver"> <property name="defaultEncoding"> <value>UTF-8</value> </property> <property name="maxUploadSize"> <value>32505856</value><!-- 上传文件大小限制为31M，31*1024*1024 --> </property> <property name="maxInMemorySize"> <value>4096</value> </property> </bean> </beans> |
⑥在 resources下新建spring-mybatis.xml配置文件，设置如下：
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 | <?xml version="1.0" encoding="UTF-8"?> <beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:tx="http://www.springframework.org/schema/tx" xmlns:aop="http://www.springframework.org/schema/aop" xsi:schemaLocation=" http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-3.0.xsd http://www.springframework.org/schema/tx http://www.springframework.org/schema/tx/spring-tx-3.0.xsd http://www.springframework.org/schema/aop http://www.springframework.org/schema/aop/spring-aop-3.0.xsd "> <!-- 配置数据源 --> <bean name="dataSource" class="com.alibaba.druid.pool.DruidDataSource" init-method="init" destroy-method="close"> <property name="url" value="${jdbc_url}" /> <property name="username" value="${jdbc_username}" /> <property name="password" value="${jdbc_password}" /> <!-- 初始化连接大小 --> <property name="initialSize" value="5" /> <!-- 连接池最大使用连接数量 --> <property name="maxActive" value="100" /> <!-- 连接池最大空闲 --> <property name="maxIdle" value="10" /> <!-- 连接池最小空闲 --> <property name="minIdle" value="0" /> <!-- 获取连接最大等待时间 --> <property name="maxWait" value="60000" /> <property name="poolPreparedStatements" value="true" /> <property name="maxPoolPreparedStatementPerConnectionSize" value="33" /> <property name="validationQuery" value="${validationQuery}" /> <property name="testOnBorrow" value="false" /> <property name="testOnReturn" value="false" /> <property name="testWhileIdle" value="true" /> <!-- 配置间隔多久才进行一次检测，检测需要关闭的空闲连接，单位是毫秒 --> <property name="timeBetweenEvictionRunsMillis" value="60000" /> <!-- 配置一个连接在池中最小生存的时间，单位是毫秒 --> <property name="minEvictableIdleTimeMillis" value="25200000" /> <!-- 打开removeAbandoned功能 --> <property name="removeAbandoned" value="true" /> <!-- 1800秒，也就是30分钟 --> <property name="removeAbandonedTimeout" value="1800" /> <!-- 关闭abanded连接时输出错误日志 --> <property name="logAbandoned" value="true" /> <!-- 监控数据库 --> <!-- <property name="filters" value="stat" /> --> <property name="filters" value="mergeStat" /> </bean> <!-- myBatis文件 --> <bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean"> <property name="dataSource" ref="dataSource" /> <!-- 自动扫描entity目录, 省掉Configuration.xml里的手工配置 --> <property name="mapperLocations" value="classpath:com/cuiyongzhi/web/mapping/*.xml" /> </bean> <bean class="org.mybatis.spring.mapper.MapperScannerConfigurer"> <property name="basePackage" value="com.cuiyongzhi.web.dao" /> <property name="sqlSessionFactoryBeanName" value="sqlSessionFactory" /> </bean> <!-- 配置事务管理器 --> <bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager"> <property name="dataSource" ref="dataSource" /> </bean> <!-- 注解方式配置事物 --> <!-- <tx:annotation-driven transaction-manager="transactionManager" /> --> <!-- 拦截器方式配置事物 --> <tx:advice id="transactionAdvice" transaction-manager="transactionManager"> <tx:attributes> <tx:method name="add*" propagation="REQUIRED" /> <tx:method name="append*" propagation="REQUIRED" /> <tx:method name="insert*" propagation="REQUIRED" /> <tx:method name="save*" propagation="REQUIRED" /> <tx:method name="update*" propagation="REQUIRED" /> <tx:method name="modify*" propagation="REQUIRED" /> <tx:method name="edit*" propagation="REQUIRED" /> <tx:method name="delete*" propagation="REQUIRED" /> <tx:method name="remove*" propagation="REQUIRED" /> <tx:method name="repair" propagation="REQUIRED" /> <tx:method name="delAndRepair" propagation="REQUIRED" /> <tx:method name="get*" propagation="SUPPORTS" /> <tx:method name="find*" propagation="SUPPORTS" /> <tx:method name="load*" propagation="SUPPORTS" /> <tx:method name="search*" propagation="SUPPORTS" /> <tx:method name="datagrid*" propagation="SUPPORTS" /> <tx:method name="*" propagation="SUPPORTS" /> </tx:attributes> </tx:advice> <aop:config> <aop:pointcut id="transactionPointcut" expression="execution(* com.cuiyongzhi.web.service..*Impl.*(..))" /> <aop:advisor pointcut-ref="transactionPointcut" advice-ref="transactionAdvice" /> </aop:config> <!-- 配置druid监控spring jdbc --> <bean id="druid-stat-interceptor" class="com.alibaba.druid.support.spring.stat.DruidStatInterceptor"> </bean> <bean id="druid-stat-pointcut" class="org.springframework.aop.support.JdkRegexpMethodPointcut" scope="prototype"> <property name="patterns"> <list> <value>com.cuiyongzhi.web.service.*</value> </list> </property> </bean> <aop:config> <aop:advisor advice-ref="druid-stat-interceptor" pointcut-ref="druid-stat-pointcut" /> </aop:config> </beans> |
⑦在 resources下新建log4j.properties配置文件，用于日志的输出等级以及输出位置设置，设置如下：
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 | log4j.rootLogger=DEBUG,Console,File #ERROR,WARN,INFO,DEBUG log4j.appender.Console=org.apache.log4j.ConsoleAppender log4j.appender.Console.Threshold=DEBUG log4j.appender.Console.Target=System.out log4j.appender.Console.layout=org.apache.log4j.PatternLayout log4j.appender.Console.layout.ConversionPattern=[%p][%d{yyyy-MM-dd HH\:mm\:ss,SSS}][%c]%m%n log4j.appender.File=org.apache.log4j.DailyRollingFileAppender log4j.appender.File.File=${catalina.base}/wechatlogs/wechat.log log4j.appender.File.Threshold=INFO log4j.appender.File.layout=org.apache.log4j.PatternLayout log4j.appender.File.Append=true log4j.appender.File.ImmediateFlush=true log4j.appender.File.DatePattern=yyyy-MM-dd‘.log‘ log4j.appender.File.layout.ConversionPattern=[%p][%d{yyyy-MM-dd HH\:mm\:ss,SSS}][%c]%m%n |
到这里springmvc+mybatis的基本配置文件基本就完成了，大致的项目结构如下：
