预览效果：
类似于之前做过的裁剪预览效果
HTML、CSS代码
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<meta http-equiv="X-UA-Compatible" content="ie=edge">
<title>Document</title>
<script src="demo.js"></script>
<style> #demo{ display: block; width: 330px; height: 220px; margin: 50px; position: relative; border: 1px solid darkorange;
} img{ width: 330px; height: 220px;
} #small-box{
/* width: 330px; */ position: relative; z-index: 1;
} #float-box{ display: none; position: absolute; background-color: #ffffcc; width: 200px; height: 125px; opacity: 0.5; cursor: move; border: 1px solid #ccc;
} #big-box{ display: none; position: absolute; top: 0; left: 400px;; width: 400px; height: 300px; overflow: hidden; border: 1px solid #ccc; z-index: 1;
} #big-box img{ width: 600px; height: 400px; position: absolute; z-index: 5;
} #mark{ position: absolute; display: block; width: 330px; height: 220px; background-color: #fff; opacity: 0; z-index: 10;
}
</style>
</head>
<body>
<div id="demo">
<div id="small-box">
<div id="mark"></div>
<div id="float-box"></div>
<img src="img1.jpg" alt="小图">
</div>
<div id="big-box">
<img src="img1.jpg" alt="大图">
</div>
</div>
</body>
</html>
JS代码：
window.onload = function(){ var demo = document.getElementById("demo"); var small_box = document.getElementById("small-box"); var big_box = document.getElementById("big-box"); var mark = document.getElementById("mark"); var float_box = document.getElementById("float-box"); var bigImg = big_box.getElementsByTagName("img")[0]; console.log(bigImg); small_box.onmouseover = function(){ big_box.style.display = "block"; float_box.style.display = "block"; } small_box.onmouseleave = function(){ big_box.style.display = "none"; float_box.style.display = "none"; } small_box.onmousemove = function(ev){ var _event = ev || window.event;//兼容不同浏览器获取事件对象的方式
var left = _event.clientX - demo.offsetLeft - small_box.offsetLeft - (float_box.offsetWidth)/2;
console.log(left); var top = _event.clientY - demo.offsetTop - small_box.offsetTop - (float_box.offsetTop)/2;
if(left < 0){ left = 0; }else if(left > (mark.offsetWidth - float_box.offsetWidth)){ left = (mark.offsetWidth - float_box.offsetWidth); console.log("max"); }; if(top < 0){ top = 0; }else if(top > (mark.offsetHeight - float_box.offsetHeight)){ top = mark.offsetHeight - float_box.offsetHeight; console.log("maxerr"); }; //开始设置float_box的位置变化
float_box.style.left = left + "px"; float_box.style.top = top + "px"; var percentX = left / (mark.offsetWidth - float_box.offsetWidth); var percentY = top / (mark.offsetHeight - float_box.offsetHeight); bigImg.style.left = - percentX *(bigImg.offsetWidth - big_box.offsetWidth) + "px" ; bigImg.style.top = - percentY *(bigImg.offsetHeight - big_box.offsetHeight) + "px"; } }
注意一个要点：
浮动框的宽/小盒子的宽 = 大盒子的宽/图片的宽
