asp.net wap开发心得
用ASP.NET开发,ASP.NET开发WAP站点,实在简单,就是一个移动控件的运用,根本不用懂WML语法.唯一不同的,就是一个ASPX文件可以支持多个FORM,不同FORM之间可以切换,
最后ASP.NET根据访问的设备,输出不同的内容,
如果用IE访问就输出HTML,手机访问,输出WML,
不过在开发过程中也遇到了很多问题,一些问题总结如下:
1.模拟器选择:
WINWAP,
M3Gate,
UP.SDK4.0,(推荐)
OPenWave 5.0 (测试时需要),
OPenWave6.2, (IIS 6.0应用,IIS5.0可能显示,但会有问题)
CheckCom WAPBrowser 3.2
模拟器问题:
ASP.NET把一些常有的模拟器,的配制信息用正则表达式写在Machine.config里
在上述的模拟器中,我只有UP.SDK4.0,OPenWave 5.0,
他们只是一个公司的产品:
需要下载,配制文件驱动更新:现在最新版本是
evice 4下载请到这里下载:
http://www.microsoft.com/downloads/details.aspx?FamilyId … B1-4DD61A5B7CCB&displaylang=en
但是,即使驱动更新以后,还是一些设备不能访问:
这时需要强制输出WML:
在web.config
添加下面内容<system.web>下
<browserCaps>
<result type=”System.Web.Mobile.MobileCapabilities, System.Web.Mobile, Version=1.0.5000.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a”/>
<use var=”HTTP_USER_AGENT”/>
preferredRenderingType = “wml11”
preferredRenderingMime = “text/vnd.wap.wml”
preferredImageMime = “image/vnd.wap.wbmp”
</browserCaps>
如果定义相关其它属性可以完整的移动设置属性:
<browserCaps>
<result type=”System.Web.Mobile.MobileCapabilities, System.Web.Mobile, Version=1.0.5000.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a”/>
<use var=”HTTP_USER_AGENT”/>
browser=Unknown
version=0.0
majorversion=0
minorversion=0
frames=false
tables=false
cookies=false
backgroundsounds=false
vbscript=false
javascript=false
javaapplets=false
activexcontrols=false
win16=false
win32=false
beta=false
ak=false
sk=false
aol=false
crawler=false
cdf=false
gold=false
authenticodeupdate=false
tagwriter=System.Web.UI.Html32TextWriter
ecmascriptversion=0.0
msdomversion=0.0
w3cdomversion=0.0
platform=Unknown
css1=false
css2=false
xml=false
mobileDeviceManufacturer = “Unknown”
mobileDeviceModel = “Unknown”
gatewayVersion = “None”
gatewayMajorVersion = “0”
gatewayMinorVersion = “0”
preferredRenderingType = “wml11”
preferredRenderingMime = “text/vnd.wap.wml”
preferredImageMime = “image/vnd.wap.wbmp”
defaultScreenCharactersWidth = “12”
defaultScreenCharactersHeight = “6”
defaultScreenPixelsWidth = “96”
defaultScreenPixelsHeight = “72”
defaultCharacterWidth = “8”
defaultCharacterHeight = “12”
screenBitDepth = “1”
isColor = “false”
inputType = “telephoneKeypad”
numberOfSoftkeys = “0”
maximumSoftkeyLabelLength = “5”
canInitiateVoiceCall = “false”
canSendMail = “true”
hasBackButton = “true”
rendersWmlDoAcceptsInline = “true”
rendersWmlSelectsAsMenuCards = “true”
rendersBreaksAfterWmlAnchor = “false”
rendersBreaksAfterWmlInput = “false”
rendersBreakBeforeWmlSelectAndInput = “true”
requiresAttributeColonSubstitution = “true”
requiresPhoneNumbersAsPlainText = “false”
requiresUrlEncodedPostfieldValues = “false”
requiredMetaTagNameValue = “”
rendersBreaksAfterHtmlLists = “true”
requiresUniqueHtmlCheckboxNames = “true”
requiresUniqueHtmlInputNames = “true”
requiresUniqueFilePathSuffix = “true”
supportsCss = “false”
hidesRightAlignedMultiselectScrollbars = “false”
canRenderAfterInputOrSelectElement = “true”
canRenderInputAndSelectElementsTogether = “true”
canRenderOneventAndPrevElementsTogether = “true”
canCombineFormsInDeck = “true”
canRenderMixedSelects = “true”
canRenderPostBackCards = “true”
canRenderSetvarZeroWithMultiSelectionList = “true”
supportsImageSubmit = “true”
supportsSelectMultiple = “true”
requiresHtmlAdaptiveErrorReporting = “false”
requiresContentTypeMetaTag = “false”
requiresDBCSCharacter = “false”
requiresOutputOptimization = “false”
supportsAccesskeyAttribute = “false”
supportsInputIStyle = “false”
supportsInputMode = “false”
supportsIModeSymbols = “false”
supportsJPhoneSymbols = “false”
supportsJPhoneMultiMediaAttributes = “false”
maximumRenderedPageSize = “2000”
requiresSpecialViewStateEncoding = “false”
requiresNoBreakInFormatting = “false”
requiresLeadingPageBreak = “false”
supportsQueryStringInFormAction = “true”
supportsCacheControlMetaTag = “true”
supportsUncheck = “true”
canRenderEmptySelects = “true”
supportsRedirectWithCookie = “true”
supportsEmptyStringInCookieValue = “true”
cachesAllResponsesWithExpires = “false”
requiresNoSoftkeyLabels = “false”
defaultSubmitButtonLimit = “1”
supportsBold = “false”
supportsItalic = “false”
supportsFontSize = “false”
supportsFontName = “false”
supportsFontColor = “true”
supportsBodyColor = “true”
supportsDivAlign = “true”
supportsDivNoWrap = “false”
supportsCharacterEntityEncoding = “true”
isMobileDevice=”false”
</browserCaps>
具体属性的意思可以考试MSDN:设备功能列表
ms-help://MS.MSDNQTR.2003FEB.2052/mwsdk/html/mwlrfDeviceCapabilitiesTable.htm
2.链接:
在同一个aspx文件,使用Link控件的,#FORM来切换不同Form时在 OPenWave 5.0测试会出现错误!
建议在程序通过ActiveForm来做
3.乱码:
如果在开发过程出现乱码,通过修改Web.Config
<globalization
requestEncoding=”gb2312″
responseEncoding=”gb2312″
/>
4.取消移动设备缓存:
Page.Response.Expires = -1;
Response.CacheControl = “Public”;
5.重定向
重定向通过
RedirectToMobilePage函数
不过使用过程中可能会出现一些问题
建议用Link控件来代替
一些开发资料:
http://msdn.microsoft.com/mobility/downloads/sdks/default.aspx
http://www.dotnet247.com/247reference/__site/72
http://www.sp-forum.org/download/list.asp?type=14
http://www2.chn.monternet.com:808 … /DevWapSimulator.jsp
http://www.tech-archive.net/Archive/DotNet/mic … et.framework.aspnet.mobile/
