微信小程序是
一种新的应用,用户不需要下载应用只用通过扫二维码或者打开链接就能使用,使用完后不需要卸载,直接关闭就行了。微信在2017年初推出微信小程序开发环境。任何企业,媒体,个人都可以注册开发。是一种全新的 开发模式。微信也因此受到许多程序员的一致好评,尤其是微信小程序的云开发,提供大量数据处理接口,让初学者也可以很快入手。不需要后端数据库的支持,自己一个人就可以开发前端和后台。
微信小程序为蓝牙模块提供了18个API。其中低功率蓝牙9个,传统蓝牙9个。本次设计使用了其中的9个接口:
(1) openBluetoothAdapter,这个API用来初始化蓝牙适配器;
(2) startBluetoothDevicesDiscovery,开始搜索蓝牙设备;
(3) onBluetoothDeviceFound,判断搜索到的蓝牙设备的信号强度;
(4) createBLEConnection,连接搜索到的蓝牙设备;
(5) stopBluetoothDevicesDiscovery,关闭搜索蓝牙设备;
(6) getBLEDeviceServices,获取蓝牙的deviceId;
(7) getBLEDeviceCharacteristics,获取蓝牙设备服务的所有特征值;
(8) notycharacteristicsId,启用低功耗蓝牙特征值的notify功能;
(9) writeBLECharacteristicValue,通过微信小程序向蓝牙模块发送命令。
js源代码
Page({ /** * 页面的初始数据 */ data: { connect: false, send_hex: false, send_string: true, send_string_val: ‘Hex‘, recv_string: true, recv_string_val: ‘Hex‘, recv_value: ‘‘, send_number: 0, recv_number: 0, recv_hex: true, wendu: 30, yanwu: 60 }, /*** 生命周期函数--监听页面加载 */ onLoad: function (options) { wx.stopBluetoothDevicesDiscovery({ success: function (res) { console.log(‘停止搜索设备‘, res) } }) console.log(options); this.setData({ deviceId: options.id, deviceName: options.name }); console.log(‘设备的ID‘, this.data.deviceId); }, /*** 生命周期函数--监听页面显示 */ onShow: function () { wx.stopBluetoothDevicesDiscovery({ success: function (res) { console.log(‘停止搜索设备‘, res) } }) var that = this; /* 连接中动画 */ wx.showLoading({ title: ‘连接中...‘, }); /* 开始连接蓝牙设备 */ wx.createBLEConnection({ deviceId: that.data.deviceId, success: function (res) { console.log(‘连接成功‘, res); wx.hideLoading(); /* 获取设备的服务UUID */ wx.getBLEDeviceServices({ deviceId: that.data.deviceId, success: function (service) { that.setData({ serviceId: "0000FFE0-0000-1000-8000-00805F9B34FB" //确定需要的服务UUID }); console.log(‘需要的服务UUID‘, that.data.serviceId) that.Characteristics(); //调用获取特征值函数 }, }); that.setData({ connect: true }) }, }) }, Characteristics: function () { var that = this; var device_characteristics = []; var characteristics_uuid = {}; wx.getBLEDeviceCharacteristics({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, success: function (res) { var characteristics = res.characteristics; //获取到所有特征值 var characteristics_length = characteristics.length; //获取到特征值数组的长度 console.log(‘获取到特征值‘, characteristics); console.log(‘获取到特征值数组长度‘, characteristics_length); that.setData({ notycharacteristicsId: "0000FFE1-0000-1000-8000-00805F9B34FB", //需确定要的使能UUID characteristicsId: "0000FFE1-0000-1000-8000-00805F9B34FB" //暂时确定的写入UUID }); console.log(‘使能characteristicsId‘, that.data.notycharacteristicsId); console.log(‘写入characteristicsId‘, that.data.characteristicsId); that.notycharacteristicsId(); //使能事件 }, }) }, /* 使能函数 */ notycharacteristicsId: function () { var that = this; var recv_value_ascii = ""; var string_value = ""; var recve_value = ""; wx.notifyBLECharacteristicValueChange({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, characteristicId: that.data.notycharacteristicsId, state: true, success: function (res) { console.log(‘使能成功‘, res); /* 设备返回值 */ wx.onBLECharacteristicValueChange(function (res) { var length_hex = []; var turn_back = ""; var result = res.value; var hex = that.buf2hex(result); console.log(‘返回的值‘, hex); if (that.data.recv_string == true) { /* 成功接收到的值的展示 */ that.setData({ recv_value: that.data.recv_value + hex }); /* 接收成功的值的字节 */ var recv_number_1 = that.data.recv_number + hex.length / 2; var recv_number = Math.round(recv_number_1); that.setData({ recv_number: recv_number }); } else { console.log(‘设备返回来的值‘, hex); var f_hex = hex; var length_soy = f_hex.length / 2; var length = Math.round(length_soy); for (var i = 0; i < length; i++) { var hex_spalit = f_hex.slice(0, 2); length_hex.push(hex_spalit); f_hex = f_hex.substring(2); } console.log(‘length_hex‘, length_hex); for (var j = 0; j < length_hex.length; j++) { var integar = length_hex[j]; //十六进制 recve_value = parseInt(integar, 16); //十进制 console.log(‘recve_value‘, recve_value); turn_back = turn_back + String.fromCharCode(recve_value); console.log(‘turn_back‘, turn_back); } console.log(‘最终转回来的值‘, turn_back) var recv_number_1 = that.data.recv_number + turn_back.length; var recv_number = Math.round(recv_number_1); that.setData({ recv_number: recv_number, recv_value: that.data.recv_value + turn_back }) } }); }, fail: function (res) { console.log(‘使能失败‘, res); } }) }, /* 断开连接 */ DisConnectTap: function () { var that = this; wx.closeBLEConnection({ deviceId: that.data.deviceId, success: function (res) { console.log(‘断开设备连接‘, res); wx.reLaunch({ url: ‘../index/index‘, }) } }); }, /*** 生命周期函数--监听页面卸载 */ onUnload: function () { var that = this; wx.closeBLEConnection({ deviceId: that.data.deviceId, success: function (res) { console.log(‘断开设备连接‘, res); } }); }, /* 清除Recv Bytes */ CleanNumberRecv: function () { this.setData({ recv_number: 0 }) }, /* ArrayBuffer类型数据转为16进制字符串 */ buf2hex: function (buffer) { // buffer is an ArrayBuffer var hexArr = Array.prototype.map.call( new Uint8Array(buffer), function (bit) { return (‘00‘ + bit.toString(16)).slice(-2) } ) return hexArr.join(‘‘); }, switch1Change: function (e) { var that = this; let buffer = new ArrayBuffer(1) let dataView = new DataView(buffer) if (e.detail.value) { dataView.setUint8(0, 0) } else { dataView.setUint8(0, 1) } wx.writeBLECharacteristicValue({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, characteristicId: that.data.characteristicsId, value: buffer, success: function (res) { console.log(‘数据发送成功‘, res); console.log(buffer); }, fail: function (res) { console.log(‘调用失败‘, res); /* 调用失败时,再次调用 */ wx.writeBLECharacteristicValue({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, characteristicId: that.data.characteristicsId, value: buffer, success: function (res) { console.log(‘第2次数据发送成功‘, res); } }) } }) }, switch1Change1: function (e) { var that = this; let buffer = new ArrayBuffer(1) let dataView = new DataView(buffer) if (e.detail.value) { dataView.setUint8(0, 2) } else { dataView.setUint8(0, 3) } wx.writeBLECharacteristicValue({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, characteristicId: that.data.characteristicsId, value: buffer, success: function (res) { console.log(‘数据发送成功‘, res); console.log(buffer); }, fail: function (res) { console.log(‘调用失败‘, res); /* 调用失败时,再次调用 */ wx.writeBLECharacteristicValue({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, characteristicId: that.data.characteristicsId, value: buffer, success: function (res) { console.log(‘第2次数据发送成功‘, res); } }) } }) }, add: function (e) { var id = e.target.id; if (this.data[id] > 98) { wx.showToast({ title: ‘已超过最大数值‘, icon: ‘loading‘, duration: 2000 }) return; } this.setData({ [id]: +this.data[id] + 1 }); this.numbers(id) }, lessen: function (e) { var id = e.target.id; if (this.data[id] < 1) { wx.showToast({ title: ‘已小于最小数值‘, icon: ‘loading‘, duration: 2000 }) return; } this.setData({ [id]: +this.data[id] - 1 }); this.numbers(id) }, changeVal: function (e) { var id = e.target.id; if (e.detail.value < 1 || e.detail.value > 100) { wx.showToast({ title: ‘请输入有效数值‘, icon: ‘loading‘, duration: 2000 }) return; } this.setData({ [id]: e.detail.value }); this.numbers(id) }, numbers: function (id) { var that = this; var number = ‘9‘; let buffer = new ArrayBuffer(1) let dataView = new DataView(buffer) console.log(id) if (id == ‘wendu‘) { number = ‘8‘ + that.data[id]; dataView.setUint8(0, 8) } else { number = number + that.data[id]; dataView.setUint8(0, number) } wx.writeBLECharacteristicValue({ deviceId: that.data.deviceId, serviceId: that.data.serviceId, characteristicId: that.data.characteristicsId, value: buffer, success: function (res) { console.log(‘数据发送成功‘, res); console.log(buffer); } }) }})
wxss源代码
.connect_box { width: 100%; height: 30px; line-height: 30px; font-size: 32rpx; color: #666; font-family: "Microsoft YaHei";}.connect_device_name{ float: left; padding-left: 10px; color: #39beff;}.connect_state { float: right; padding-right: 10px; text-decoration: underline; color: #39beff;}.fan{ width: 2rem; height: 2rem; vertical-align: middle; margin-left: 2.25rem; margin-right: 0.25rem;}.water{ width: 2.5rem; height: 2rem; vertical-align: middle; margin-left: 2rem;}.name{ display: inline-block; width: 22%; margin-left: 1.5rem; font-size: 0.9rem;}.key{ float: right; margin-right: 2rem; margin-top: 0.2rem;}.detail_box{ padding: 1.5rem 0; border-bottom: 1px solid #ccc;}.num { display: inline-block; width: 45%; text-align: right; vertical-align: middle;}.num input { display: inline-block; width: 2rem; text-align: center; border: 1px solid #f2f2f2; border-left: none; border-right: none; color: #a2a2a2;}.num text { display: inline-block; width: 1.4rem; height: 1.4rem; line-height: 1.4rem; text-align: center; border: 1px solid #f2f2f2; vertical-align: top; color: #dcdcdc;}.wendu{ width:1.9rem; height:2rem; vertical-align:middle; margin-left:2.3rem; margin-right:.3rem;}
wxml源代码
<view class="connect_box"> <text class=‘connect_device_name‘>{{deviceName}}</text> <text wx:if="{{connect}}" class="connect_state" catchtap="DisConnectTap">已连接</text> <text wx:else class="connect_state">未连接</text></view><view > <view class="detail_box"> <image src=‘../../images/airFan.png‘ class="fan"></image> <view class=‘name‘>风扇</view> <switch bindchange="switch1Change" class=‘key‘ /> </view> <view class="detail_box"> <image src=‘../../images/waterPump.png‘ class="water"></image> <view class=‘name‘>水泵</view> <switch bindchange="switch1Change1" class=‘key‘ /> </view> <view class="detail_box"> <image src=‘../../images/temperature.png‘ class="wendu"></image> <view class=‘name‘>温度阀值</view> <view class=‘num‘> <text style=‘border-radius: 3px 0 0 3px;‘ id=‘wendu‘ bindtap=‘lessen‘>-</text> <input type=‘number‘ value=‘{{wendu}}‘ name=‘piece‘ id=‘wendu‘ bindblur="changeVal" /> <text style=‘border-radius: 0 3px 3px 0;‘ id=‘wendu‘ bindtap=‘add‘>+</text> </view> </view> <view class="detail_box"> <image src=‘../../images/smog.png‘ class="water"></image> <view class=‘name‘>烟雾阀值</view> <view class=‘num‘> <text style=‘border-radius: 3px 0 0 3px;‘ id=‘yanwu‘ bindtap=‘lessen‘>-</text> <input type=‘number‘ value=‘{{yanwu}}‘ name=‘piece‘ id=‘yanwu‘ bindblur="changeVal" /> <text style=‘border-radius: 0 3px 3px 0;‘ id=‘yanwu‘ bindtap=‘add‘>+</text> </view> </view> </view>
微信小程序展示页面
微信小程序不能在电脑上模拟,智能用手机操作,我们需要用手机打开我们的微信小程序。首先如果手机蓝牙没有打开回提醒打开蓝牙重新加载。如果手机蓝牙打开了就会去搜索附近的蓝牙模块,搜索到自己的低功率蓝牙,点击就可以连接到自己的蓝牙。我们就到了控制页面。
我们可以通过微信小程序风扇和水泵。点击开关时会调用writeBLECharacteristicValue接口通过蓝牙模块给单片机发送指令,控制单片机上的风扇和水泵等硬件设备。
2.硬件设备介绍
硬件部分主要介绍单片机、低功率蓝牙、风扇和水泵。单片机用什么型号的都行,都能与蓝牙模块正常通信,收发数据。低功率蓝牙主要优点是功率低,寿命长,价格便宜。多用于硬件连接上位机软件。风扇和水泵是外接设备,由单片机控制。
1.单片机
单片机的型号是stc89c52rc,STC89C52RC是STC公司生产的一种低功耗、高性能CMOS8位微控制器,具有8K字节系统可编程Flash存储器。STC89C52使用经典的MCS-51内核,但是做了很多的改进使得芯片具有传统的方法51单片机不具备的功能。在单芯片上,拥有灵巧的8 位CPU 和在系统可编程Flash,使得STC89C52为众多嵌入式控制应用系统提供高灵活、超有效的解决方案。
2.蓝牙模块
我用的是蓝牙型号是HC-06,给HC-06上电之后,HC-06的指示灯会不停地闪烁,这个时候就标志着进入AT模式了,配置的时候,HC-06的Rx和Tx 接到 51单片机的 Rx和 Tx,一般是P3.0,和P3.1,正常工作时,HC-06的Rx和Tx 接到 51单片机的 Tx和 Rx,8位数据位,1位结束位,无奇偶校验。一般HC-06模块的默认名称就是hc-06,默认配对密码是1234或0000。我们如果连接微信小程序,我们要把密码取消,这样微信小程序才能直接来连接。
3.风扇和水泵
风扇和水泵是直接供电就可以使用,我们只需要一个继电器就可以控制这两个设备,我选择了P3.5,P3.4这两个引脚来控制,高电平驱动,低电平关闭,这两个外接设备主要是测试数据有没有接受成功。
单片机程序主程序
void ctrl(unsigned char a) //单字节数据接收{ //注意:若单片机TXD(P3.1)无上拉能力,必须在P3.1端接上拉电阻。本次测试需要接上拉电阻 TI=0; SBUF=a; while(TI==0); TI=0; Mode=1; if(SBUF==0){ LED_yanwu=0; baojing=0; fs=0; led1=0; led2=0; }else if(SBUF==1){ LED_yanwu=1; baojing=1; fs=1; Mode=0; }else if(SBUF==2){ baojing=0; LED_wendu=0; fs1=0; }else if(SBUF==3){ baojing=1; LED_wendu=1; fs1=1; led1=0; led2=0; Mode=0; }} void main(){ check_wendu(); check_wendu(); Init1602(); ES=0; //关中断 SCON = 0x50; // REN=1允许串行接受状态,串口工作模式1, //10位UART(1位起始位,8位数据位,1位停止位,无奇偶校验),波特率可变 TMOD = 0x20; // 定时器1工作于方式2,8位自动重载模式, 用于产生波特率 TH1=TL1=0xFD; // 波特率9600 (本次测试采用晶振为11.0592) PCON &= 0x7f; // 波特率不倍增 TR1 = 1; //定时器1开始工作,产生波特率 TI=0; //接收标志位置0 RI=0; ES=1; while(1) { temp=ADC0809(); check_wendu(); Key(); if(RI==1) // 是否有数据到来 { RI = 0; ctrl(SBUF); } Display_1602(yushe_wendu,yushe_yanwu,c,temp); //c温度值,temp烟雾值 if(Mode==0) { if(temp>=yushe_yanwu) { LED_yanwu=0; baojing=0; fs=0; } else { LED_yanwu=1; } if(c>800){ c = 0; } if(c>=(yushe_wendu*10)) { baojing=0; LED_wendu=0; fs1=0; } else { LED_wendu=1; } if((temp<yushe_yanwu)&&(c<(yushe_wendu*10))) { baojing=1; fs=1; fs1=1; } } }}
硬件实物图
数据采集显示正常,微信小程序可以正常控制单片机的水泵和风扇,通信正常无异常。硬件部分我就简单的拿出来说了一下,所涉及到的知识肯定比我展示到的多,软件部分主要是对低功率蓝牙的搜索,连接,发送数据比较麻烦。
视频链接:
有什么不太明白的或者我讲的不清楚的可以加我QQ详谈:
