某客户通过监控发现某一套Oracle DB在一个时间段内的,异常指标!需要进行分析
使用如下SQL进行诊断,发现TOP EVENT 是SQL*Net break/reset to client
SQL>select instance_number,event,count(*) from dba_hist_active_sess_history
where SAMPLE_TIME between to_date(‘2020-02-25 06‘,‘yyyy-mm-dd hh24‘) and
to_date(‘2020-02-25 09‘,‘yyyy-mm-dd hh24‘) and
having(count(*))>200 group by instance_number,event order by 2;
查询11g官方文档获取该等待事件解释说明,基本上与应用执行的程序=SQL有关系
SQL*Net break/reset to client (%)Description The server is sending a break or reset message to the client. The session running on the server is waiting for a reply
from the client.These waits are caused by an application attempting to:Select from a closed cursorSelect on a cursor after the last row has already been fetched and no data has been returnedSelect on a non-existent tableInsert a duplicate row into a uniquely indexed tableIssuing a query with invalid syntax If the value, v$session_wait.p2, for this parameter equals 0, it means a reset was sent to the client. A non-zero value
means that the break was sent to the client.
使用如下SQL 可以查询到执行SQL的用户ID=DBA_USER USER_ID=>USERNAME 以及SQL_id
SQL>select event,USER_ID,sql_id,count(*) from dba_hist_active_sess_history where SAMPLE_TIME
between to_date(‘2020-02-25 06‘,‘yyyy-mm-dd hh24‘) and to_date(‘2020-02-25 09‘,‘yyyy-mm-dd hh24‘)
and instance_number=1 and event=‘SQL*Net break/reset to client‘ group by USER_ID,event,sql_id order by 2;
数据库并未找到SQL文本,但是该库存在监控,通过监控输入SQL_ID找到SQL_TEXT 发现是查询视图!
由于本次问题,开发人员自己处理了,因此并未造成影响。开发也并未反馈是什么原因。如下进行测试模拟参考文档!
https://tanelpoder.com/2008/04/10/sqlnet-breakreset-to-client/
如下是测试内容
SQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);SQL> begin execute immediate ‘drop table non_existent‘; exception when others then null; end; /SQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);null
上述可以发现,当查询一个不存在的表,但是PLSQL存在异常处理部分,并不会出现本次测试的等待事件!
SQL> begin execute immediate ‘drop table non_existent‘; end; /SQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);EVENT TOTAL_WAITS------------------------------ -----------SQL*Net break/reset to client 2
上述可以发现,当查询一个不存在的表,但是PLSQL不存在异常处理部分,该等待事件出现!
查询一个不存在的表!
SQL> select * from non_existent;select * from non_existent *ERROR at line 1:ORA-00942: table or view does not existSQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);EVENT TOTAL_WAITS------------------------------ -----------SQL*Net break/reset to client 4创建一个表,后置查询一个不存在的表!SQL> create table a as select * from employees;create table a as select * from employees *ERROR at line 1:ORA-00942: table or view does not existSQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);EVENT TOTAL_WAITS------------------------------ -----------SQL*Net break/reset to client 6查询一个视图,视图对应的表被删除SQL> create table a as select * from hr.employees;SQL> create view a_t as select EMPLOYEE_ID,FIRST_NAME from a;SQL> drop table a;SQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);EVENT TOTAL_WAITS------------------------------ -----------SQL*Net break/reset to client 6SQL> select * from a_t;select * from a_t *ERROR at line 1:ORA-04063: view "SYS.A_T" has errorsSQL> select event, total_waits from v$session_event where event like ‘%reset%‘ and sid = (select sid from v$mystat where rownum = 1);EVENT TOTAL_WAITS------------------------------ -----------SQL*Net break/reset to client 8
